Event synchronization mechanism

The event synchronization mechanism provides a channel for publishing events that occur within the collaborative engine. The client system can consume these events and combine them with its own business to take the next step.

How to use event synchronization mechanism?

Currently supported for collaborative event synchronization:

• Collaborative editing: changeset successfully stored

How to use event synchronization mechanism

Starting to use the event synchronization mechanism is very simple.

1. Turn on event synchronization switch
2. Initiate Consumer Event

Turn on event synchronization switch

Go to docker-compose directory, edit the .env file, find and set EVENT_SYNC to true:

EVENT_SYNC=true

Run the following command to restart the service:

bash run.sh

Code Snippet for consumer

Refer to https://github.com/dream-num/univer-event-sync-example-go

Data structures

message EventSyncData {
  string eventId = 1;
  string eventType = 2; // type of event, now support changeset
  int32 createdAt = 3;
  oneof event {
    univer.ChangesetAck csAckEvent = 4;
    // more event types in the future.
  }
}

message ChangesetAck {
    univer.Changeset cs = 1;
}

message Changeset {
    string unitID = 1; // unitID of the Univer document
    univer.constants.UniverType type = 2;
    int32 baseRev = 3;
    int32 revision = 4;
    string userID = 5;
    repeated Mutation mutations = 6;
    string memberID = 7;
}

message Mutation {
    string id = 1; // ID of the mutation
    string data = 2; // serialized params
}
