Data Validation

Mobile SupportOptimized UI for touch devices

Data validation is a feature that allows you to set rules in cells to ensure that the data entered meets specific requirements. It helps users avoid input errors and improves the accuracy and consistency of data.

Currently, the following data validation types are supported:

Number
Integer
Text length
Date
Checkbox
Dropdown list (single/multiple selection)
Custom formula

Preset Mode

Installation

npm install @univerjs/preset-sheets-data-validation

Usage

import { UniverSheetsCorePreset } from '@univerjs/preset-sheets-core'
import UniverPresetSheetsCoreEnUS from '@univerjs/preset-sheets-core/locales/en-US'
import { UniverSheetsDataValidationPreset } from '@univerjs/preset-sheets-data-validation'
import UniverPresetSheetsDataValidationEnUS from '@univerjs/preset-sheets-data-validation/locales/en-US'
import { createUniver, LocaleType, mergeLocales } from '@univerjs/presets'

import '@univerjs/preset-sheets-core/lib/index.css'
import '@univerjs/preset-sheets-data-validation/lib/index.css'

const { univerAPI } = createUniver({
  locale: LocaleType.En_US,
  locales: {
    [LocaleType.En_US]: mergeLocales(
      UniverPresetSheetsCoreEnUS,
      UniverPresetSheetsDataValidationEnUS,
    ),
  },
  presets: [
    UniverSheetsCorePreset(),
    UniverSheetsDataValidationPreset(),
  ],
})

Presets and Configuration

UniverSheetsDataValidationPreset({
  /**
   * Whether to display the edit button in the drop-down menu
   * @default true
   */
  showEditOnDropdown: true,
  /**
   * Whether to display the search box in the drop-down menu
   * @default true
   */
  showSearchOnDropdown: true,
})

Complete configuration options can be found in the IUniverSheetsDataValidationPresetConfig.

Plugin Mode

Installation

npm install @univerjs/data-validation @univerjs/sheets-data-validation @univerjs/sheets-data-validation-ui

Usage

import { LocaleType, mergeLocales, Univer } from '@univerjs/core'
import { UniverDataValidationPlugin } from '@univerjs/data-validation'
import { UniverSheetsDataValidationPlugin } from '@univerjs/sheets-data-validation'
import { UniverSheetsDataValidationUIPlugin } from '@univerjs/sheets-data-validation-ui'
import SheetsDataValidationEnUS from '@univerjs/sheets-data-validation-ui/locale/en-US'

import '@univerjs/sheets-data-validation-ui/lib/index.css'

import '@univerjs/sheets-data-validation/facade'

const univer = new Univer({
  locale: LocaleType.En_US,
  locales: {
    [LocaleType.En_US]: mergeLocales(
      SheetsDataValidationEnUS,
    ),
  },
})

univer.registerPlugin(UniverDataValidationPlugin)
univer.registerPlugin(UniverSheetsDataValidationPlugin)
univer.registerPlugin(UniverSheetsDataValidationUIPlugin)

Plugins and Configuration

univer.registerPlugin(UniverSheetsDataValidationUIPlugin, {
  /**
   * Whether to display the edit button in the drop-down menu
   * @default true
   */
  showEditOnDropdown: true,
  /**
   * Whether to display the search box in the drop-down menu
   * @default true
   */
  showSearchOnDropdown: true,
})

Complete configuration options can be found in the IUniverSheetsDataValidationUIConfig.

Facade API

Complete Facade API type definitions can be found in the FacadeAPI.

Importing

Plugin mode note

Only plugin mode requires manually importing the Facade package. Preset mode already includes the corresponding Facade package, so no extra import is needed.

import '@univerjs/sheets-data-validation/facade'

Add a data validation rule

univerAPI.newDataValidation() can create a new data validation builder, which returns an FDataValidationBuilder instance that can generate data validation rules through chained calls.

Here are some member methods on FDataValidationBuilder:

Method	Description
build	Build the data validation rule.
requireCheckbox	Sets the data validation rule to require that the input is a boolean value; this value is rendered as a checkbox
requireDateAfter	Set the data validation type to DATE and configure the validation rules to be after a specific date
requireDateBefore	Set the data validation type to DATE and configure the validation rules to be before a specific date
requireDateBetween	Set the data validation type to DATE and configure the validation rules to be within a specific date range
requireDateEqualTo	Set the data validation type to DATE and configure the validation rules to be equal to a specific date
requireDateNotBetween	Set the data validation type to DATE and configure the validation rules to be not within a specific date range
requireDateOnOrAfter	Set the data validation type to DATE and configure the validation rules to be on or after a specific date
requireDateOnOrBefore	Set the data validation type to DATE and configure the validation rules to be on or before a specific date
requireFormulaSatisfied	Sets the data validation rule to require that the given formula evaluates to `true`
requireNumberBetween	Sets the data validation rule to require a number that falls between, or is either of, two specified numbers
requireNumberEqualTo	Sets the data validation rule to require a number equal to the given value
requireNumberGreaterThan	Sets the data validation rule to require a number greater than the given value
requireNumberGreaterThanOrEqualTo	Sets the data validation rule to require a number greater than or equal to the given value
requireNumberLessThan	Sets the data validation rule to require a number less than the given value
requireNumberLessThanOrEqualTo	Sets the data validation rule to require a number less than or equal to the given value
requireNumberNotBetween	Sets the data validation rule to require a number that does not fall between, and is neither of, two specified numbers
requireNumberNotEqualTo	Sets the data validation rule to require a number not equal to the given value
requireValueInList	Sets a data validation rule that requires the user to enter a value from a list of specific values. Supports single/multiple selection and show/hide dropdown
requireValueInRange	Sets a data validation rule that requires the user to enter a value within a specific range. Supports single/multiple selection and show/hide dropdown
setOptions	Sets the options for the data validation rule

const fWorkbook = univerAPI.getActiveWorkbook()
const fWorksheet = fWorkbook.getActiveSheet()

// Create a new data validation rule that requires a number between 1 and 10 for the range A1:B10
const fRange = fWorksheet.getRange('A1:B10')
const rule = univerAPI.newDataValidation()
  .requireNumberBetween(1, 10)
  .setOptions({
    allowBlank: true,
    showErrorMessage: true,
    error: 'Please enter a number between 1 and 10',
  })
  .build()
fRange.setDataValidation(rule)

Clear data validations of range

const fWorkbook = univerAPI.getActiveWorkbook()
const fWorksheet = fWorkbook.getActiveSheet()

// Clear data validation of range A1:B10
const fRange = fWorksheet.getRange('A1:B10')
fRange.setDataValidation(null)

Get data validations of Range / Worksheet

The returned data validation rule object is an FDataValidation instance, which can be used to obtain the conditions, options, etc. of the validation rule.

Here are some member methods on FDataValidation:

Method	Description
copy	Creates a new instance of FDataValidationBuilder using the current rule object
getCriteriaType	Gets the data validation type of the rule
getCriteriaValues	Gets the values used for criteria evaluation
getHelpText	Gets the help text information, which is used to provide users with guidance and support
getRanges	Gets the ranges to which the data validation rule is applied
setCriteria	Set Criteria for the data validation rule
setOptions	Set the options for the data validation rule
setRanges	Set the ranges to the data validation rule
delete	Delete the data validation rule from the worksheet

const fWorkbook = univerAPI.getActiveWorkbook()
const fWorksheet = fWorkbook.getActiveSheet()

// Get all data validation rules in current sheet.
const rulesOfSheet = fWorksheet.getDataValidations()

// Get a data validation rule by rule ID.
const ruleById = fWorksheet.getDataValidation(rulesOfSheet[0]?.rule?.uid)

const fRange = fWorksheet.getRange('A1:B10')

// Get first data validation rule in current range.
const ruleOfRange = fRange.getDataValidation()
console.log('ruleOfRange:', ruleOfRange, ruleOfRange?.getCriteriaValues())

// Get all data validation rules in current range.
const rulesOfRange = fRange.getDataValidations()

Update/Delete data validation

const fWorkbook = univerAPI.getActiveWorkbook()
const fWorksheet = fWorkbook.getActiveSheet()

// Create a new data validation rule that requires a number equal to 20 for the range A1:B10
const fRange = fWorksheet.getRange('A1:B10')
const rule = univerAPI.newDataValidation()
  .requireNumberEqualTo(20)
  .build()
fRange.setDataValidation(rule)

const newRuleRange = fWorksheet.getRange('C1:D10')

// Update the rule after 3 seconds
setTimeout(() => {
  fRange.getDataValidation()
    // Change the range to C1:D10
    .setRanges([newRuleRange])
    // Change the criteria to require a number between 1 and 10
    .setCriteria(
      univerAPI.Enum.DataValidationType.DECIMAL,
      [univerAPI.Enum.DataValidationOperator.BETWEEN, '1', '10'],
    )
    // Change option to stop input on validation errors and show error message
    .setOptions({
      allowBlank: true,
      showErrorMessage: true,
      error: 'Please enter a valid value',
      errorStyle: univerAPI.Enum.DataValidationErrorStyle.STOP,
    })
}, 3000)

// Delete the rule after 6 seconds
setTimeout(() => {
  newRuleRange.getDataValidation().delete()
}, 6000)

Get validation errors

const fWorkbook = univerAPI.getActiveWorkbook()
const fWorksheet = fWorkbook.getActiveSheet()

// Get all data validation errors for current workbook.
const workbookErrors = await fWorkbook.getAllDataValidationErrorAsync()
console.log('workbookErrors:', workbookErrors)

// Get all data validation errors for current sheet.
const worksheetErrors = await fWorksheet.getAllDataValidationErrorAsync()
console.log('worksheetErrors:', worksheetErrors)

// Get data validation errors for current range.
const fRange = fWorksheet.getRange('A1:B10')
const rangeErrors = await fRange.getDataValidationErrorAsync()
console.log('rangeErrors:', rangeErrors)

Each error object contains the following fields:

sheetName: The name of the worksheet where the error occurred
row: The row index of the cell that triggered the error
column: The column index of the cell that triggered the error
ruleId: The ID of the rule that triggered the error
inputValue: The input value that triggered the error
rule: The rule content snapshot

Get validator status

The validator status is an enum value of DataValidationStatus, which includes:

valid: The cell value passes validation
invalid: The cell value fails validation
validating: The cell is being validated

const fWorkbook = univerAPI.getActiveWorkbook()
const fWorksheet = fWorkbook.getActiveSheet()

// Get data validation validator status for current workbook.
fWorkbook.getValidatorStatus().then((status) => {
  console.log('===statusOfWorkbook', status)
})

// Get data validation validator status for current sheet.
fWorksheet.getValidatorStatusAsync().then((status) => {
})

// Get data validation validator status for current range.
const fRange = fWorksheet.getRange('A1:B10')
fRange.getValidatorStatus().then((status) => {
  console.log('===tatusOfRange', status)
})

Event Listeners

Full event type definitions, please refer to Events.

The data validation module provides a series of events for monitoring validation rule additions, updates, deletions, and validation status changes. All events can be listened to using univerAPI.addEvent().

Validation Rule Change Events

univerAPI.Event.SheetDataValidationChanged: Triggered after a validation rule changes

const disposable = univerAPI.addEvent(univerAPI.Event.SheetDataValidationChanged, (params) => {
  const { origin, worksheet, workbook, changeType, oldRule, rule } = params
})

// Remove the event listener, use `disposable.dispose()`

univerAPI.Event.BeforeSheetDataValidationAdd: Triggered before adding a validation rule

const disposable = univerAPI.addEvent(univerAPI.Event.BeforeSheetDataValidationAdd, (params) => {
  const { worksheet, workbook, rule } = params

  // Cancel the data validation rule addition operation
  params.cancel = true
})

// Remove the event listener, use `disposable.dispose()`

univerAPI.Event.BeforeSheetDataValidationDelete: Triggered before deleting a validation rule

const disposable = univerAPI.addEvent(univerAPI.Event.BeforeSheetDataValidationDelete, (params) => {
  const { worksheet, workbook, ruleId, rule } = params

  // Cancel the data validation rule deletion operation
  params.cancel = true
})

// Remove the event listener, use `disposable.dispose()`

univerAPI.Event.BeforeSheetDataValidationDeleteAll: Triggered before deleting all validation rules

const disposable = univerAPI.addEvent(univerAPI.Event.BeforeSheetDataValidationDeleteAll, (params) => {
  const { worksheet, workbook, rules } = params

  // Cancel the data validation rule deletion operation
  params.cancel = true
})

// Remove the event listener, use `disposable.dispose()`

Validation Rule Update Events

univerAPI.Event.BeforeSheetDataValidationCriteriaUpdate: Triggered before updating validation rule criteria

const disposable = univerAPI.addEvent(univerAPI.Event.BeforeSheetDataValidationCriteriaUpdate, (params) => {
  const { worksheet, workbook, ruleId, rule, newCriteria } = params

  // Cancel the data validation rule criteria update operation
  params.cancel = true
})

// Remove the event listener, use `disposable.dispose()`

univerAPI.Event.BeforeSheetDataValidationRangeUpdate: Triggered before updating validation rule ranges

const disposable = univerAPI.addEvent(univerAPI.Event.BeforeSheetDataValidationRangeUpdate, (params) => {
  const { worksheet, workbook, ruleId, rule, newRanges } = params

  // Cancel the data validation rule range update operation
  params.cancel = true
})

// Remove the event listener, use `disposable.dispose()`

univerAPI.Event.BeforeSheetDataValidationOptionsUpdate: Triggered before updating validation rule options

const disposable = univerAPI.addEvent(univerAPI.Event.BeforeSheetDataValidationOptionsUpdate, (params) => {
  const { worksheet, workbook, ruleId, rule, newOptions } = params

  // Cancel the data validation rule options update operation
  params.cancel = true
})

// Remove the event listener, use `disposable.dispose()`

Validation Status Events

univerAPI.Event.SheetDataValidatorStatusChanged: Triggered when a cell's validation status changes

const disposable = univerAPI.addEvent(univerAPI.Event.SheetDataValidatorStatusChanged, (params) => {
  const { worksheet, workbook, row, column, status, rule } = params
})

// Remove the event listener, use `disposable.dispose()`

Each event includes the following common parameters:

workbook: Current workbook instance
worksheet: Current worksheet instance

Special parameters:

rule: The related validation rule object
ruleId: Unique identifier of the validation rule
status: Validation status (only in SheetDataValidatorStatusChanged event)
newCriteria: New validation criteria (only in BeforeSheetDataValidationCriteriaUpdate event)
newRanges: New validation ranges (only in BeforeSheetDataValidationRangeUpdate event)
newOptions: New validation options (only in BeforeSheetDataValidationOptionsUpdate event)

All event callbacks with the Before prefix can use params.cancel = true to prevent the corresponding operation.

Error style

The errorStyle option controls the behavior when invalid data is entered. It is an enum value of DataValidationErrorStyle, which includes:

STOP: Prevents the user from entering invalid data
WARNING: Allows the user to enter invalid data, but displays a warning
INFO: Allows the user to enter invalid data, but displays an information message

const fWorkbook = univerAPI.getActiveWorkbook()
const fWorksheet = fWorkbook.getActiveSheet()
const fRange = fWorksheet.getRange('A1:B10')

const rule = univerAPI.newDataValidation()
  .requireNumberBetween(1, 10)
  .setOptions({
    allowBlank: true,
    showErrorMessage: true,
    error: 'Please enter a number between 1 and 10',
    errorStyle: univerAPI.Enum.DataValidationErrorStyle.STOP,
  })
  .build()
fRange.setDataValidation(rule)

Change List render mode

const fWorkbook = univerAPI.getActiveWorkbook()
const fWorksheet = fWorkbook.getActiveSheet()
const fRange = fWorksheet.getRange('A1:B10')

fRange.getDataValidation()?.setOptions({
  // support TEXT, ARROW, CUSTOM
  // default is `CUSTOM`
  renderMode: univerAPI.Enum.DataValidationRenderMode.TEXT,
})

Table of Contents
